PAWA PRO 5600 Solar Inverter (4000VA/4000W)

The PAWA PRO 5600 Solar Inverter is a powerful and efficient solution for both home and office energy needs. Designed with advanced MPPT solar charging technology, dual output for smart load management, and built-in WiFi for mobile monitoring, this inverter ensures uninterrupted, stable, and intelligent power delivery.

🔋 Key Specifications

• Rated Power: 4000VA / 4000W

• Input Voltage: 230 VAC

• Selectable Voltage Range:

  • 170–280 VAC (For Personal Computers)

  • 90–280 VAC (For Home Appliances)

• Frequency Range: 50Hz / 60Hz (Auto Sensing)

• Output Voltage Regulation: 230 VAC ±10%

• Surge Power: 8000VA

• Efficiency (Peak): 93%

• Waveform: Pure Sine Wave

• Transfer Time:

  • 10 ms (For PCs)

  • 20 ms (For Home Appliances)

🔋 Battery & Charging

• Battery Voltage: 24VDC

• Floating Charge Voltage: 27VDC

• Overcharge Protection: 33VDC

• Solar Charger Type: MPPT

• Maximum PV Array Power: 5600W

• MPPT Range @ Operating Voltage: 60–450VDC

• Maximum PV Input Current: 27A

• Maximum Solar Charge Current: 120A

• Maximum AC Charge Current: 100A

• Combined Max Charge Current: 120A

⚙️ Features

• Dual output for smart load management

• Customizable LED ring with RGB lights

• 4.3” colored LCD touchable display

• Built-in WiFi for mobile app monitoring & OTA updates

• Built-in BMS communication port

• USB On-the-Go support

• Integrated anti-dust kit

• Battery-independent design

🧰 Physical & Environmental Details

• Dimensions: 119 × 313.6 × 457.5 mm

• Net Weight: 10 kg

• Communication Interface: USB / RS232 / RS485 / WiFi / Dry-contact

• Humidity: 5%–95% (Non-condensing)

• Operating Temperature: -10°C to 50°C

• Storage Temperature: -15°C to 60°C

🛡️ Warranty

1 Year Parts + 4 Years Service Warranty
